RF Enclosure Mini Extended FX - Aluminum - with Mounting Flange
Reference:
Universal aluminum RF enclosure.
Designed for radio-frequency applications, test systems, and rapid prototyping.
SMA connectors and both the bottom- and top-cover are easily (dis)assembled to support easy exchange of PCBs for experimentation purposes.
This module features two mounting flanges.
115 Items
Volume discounts
Quantity | Discount | You Save |
---|---|---|
5 | 2% | Up to 9,90 € |
10 | 3% | Up to 29,70 € |
More info
Order information: please select the correct "Number of SMA connectors".
RF enclosure features.
- Milled aluminum enclosure
- Feed through capacitor
- Turret terminal
- 1 to 5 SMA connectors
- Blind cover plates for unused SMA ports
- Supports PCB thickness between 0 and 1.6 mm (63 mil)
- Top and bottom cover plates
- Complete set of screws
- Excellent RF shielding
Additional information:
See also :
- RF Enclosure Mini-Extended-FX: a new universal enclosure for RF circuits
- Landing Pad Design for an SMA Connector Using an RF Enclosure MINI
Download
Datasheet of the RF enclosure MINI-EXT-FX
Download (859.7k)Application note RF Enclosure Mini EXT-FX
Download (2.2M)
